UHAND FS-10 10m³ High-Efficiency Electric Feed Distribution Wagon
Product Overview
The UHAND FS-10 marks a significant upgrade in capacity and efficiency, offering a robust 10m³ solution for medium-sized livestock farms. Designed for higher-intensity feeding operations, this model is powered by a more potent engine and features an advanced electric control system. The FS-10 combines substantial volume with precise weighing and ease of operation, dramatically reducing labor intensity while ensuring accurate, uniform feed distribution for larger herds.
Key Features & Benefits
-
Significant Capacity Upgrade: The 10m³ hopper is designed to handle larger feed volumes, reducing the number of refill trips and increasing daily operational efficiency for medium-sized herds.
-
User-Friendly Electric Control: Upgraded from manual to an intuitive electric control system, significantly reducing operator effort and simplifying the feeding process.
-
Precise Metering for Cost Control: Standard-equipped with a high-precision weighing system, ensuring accurate ration delivery to manage feed costs effectively and minimize waste.
-
Powerful Performance: Paired with a higher horsepower engine (115/150 hp) and increased load capacity (8000 kg), built to handle heavier workloads with ease.
-
Robust & Reliable Construction: Features durable high-strength steel construction and a proven cottered chain drive system for long-term reliability in demanding farm conditions.
Application Scenarios
-
Medium-Sized Dairy & Livestock Farms: The ideal workhorse for farms requiring higher daily feed throughput and efficiency.
-
Operations Seeking Reduced Labor Intensity: Perfect for farms looking to upgrade from manual-control machines to an easier, more automated electric system.
-
Farms with Standard Barn Aisle Widths: Suitable for barns that can accommodate its slightly larger 2250mm width.
Technical Specifications
| Parameter |
Specification |
| Model |
FS-10 |
| Capacity |
10 m³ |
| Overall Dimensions (L×W×H) |
6450 × 2250 × 2560/2660 mm |
| Compatible Vehicle |
Kaima |
| Emission Standard |
National V/VI |
| Engine Power |
115 hp / 150 hp |
| Max Load Capacity |
8000 kg |
| Machine Weight |
5800 kg |
| PTO Method |
Direct Engine |
| Hopper Drive Type |
Chain Plate |
| Chain Model |
Cottered Chain |
| Chain Quantity |
2 |
| Control Method |
Electric |
Note: Product images are for illustrative purposes only. Actual product may vary. Specifications are subject to change without notice due to continuous improvement. Please consult our sales team for the latest information.
Frequently Asked Questions
Q1: What are the main upgrades in the FS-10 compared to smaller models like the FS-07?
A1: The FS-10 offers a larger 10m³ capacity, a significant increase in max load capacity (to 8000kg), more powerful engine options, and most importantly, it upgrades from manual to an easy-to-use electric control system.
Q2: How does the electric control system benefit the operator?
A2: The electric control system simplifies operation, allowing the driver to control feeding functions with switches from the cab. This greatly reduces physical labor and fatigue compared to manual lever operation.
Q3: Is this model suitable for narrow barns?
A3: The FS-10 has a width of 2250mm, which is wider than the smaller models. Please ensure your barn aisles are wide enough to accommodate this machine comfortably.
